Faital Pro HF1400 - 1.4" Hochtontreiber, 8 Ohm
Faital Pro HF1400 - 1.4" Hochtontreiber, 8 Ohm
Datenblatt
| Nominal Impedance | 8 Ohm |
| Minimum Impedance | 7 Ohm |
| AES Power above 0.9 kHz (1) | 100 W |
| AES Power above 0.65 kHz | 50 W |
| Maximum Power above 0.9 kHz (2) | 200 W |
| Maximum Power above 0.65 kHz | 100 W |
| Minimum Crossover Frequency (3) | 0.9 kHz |
| Sensitivity (1W/1m) (4) | 110 dB |
| Frequency Range | 0.5÷18 kHz |
| Voice Coil Diameter | 74 mm (2.91 in) |
| Diaphragm Material | Titanium |
| Diaphragm Shape | Dome |
| Flux Density | 1.95 T |
| Re | 5.6 Ohm |
| Phase Plug Design | Annular |
